1. Flow range of steam vortex flowmeter
The flow range of steam vortex flowmeter varies depending on its model and diameter. The diameter (DN) represents the diameter of the pipeline, while the flow range represents the flow value that the flowmeter can measure. The model OW-LU-25 is suitable for DN25 pipelines, with a flow range of liquid 1-10 m ³/h and gas 25-60 m ³/h. For steam flow, it is recommended to refer to the instruction manual. For large pipelines above DN300, it is recommended to use an inserted vortex flowmeter. The model OW-LU-32 is suitable for DN32 pipelines, with a flow range of 1.5-18 m ³/h for liquids and 15-150 m ³/h for gases. The model OW-LU-40 is suitable for DN40 pipelines, with a flow range of 2.2-27 m ³/h for liquids and 22.6-150 m ³/h for gases. The model OW-LU-50 is suitable for DN50 pipelines, with a flow range of liquid 4~55 m ³/h and gas 35~350 m ³/h. The model OW-LU-80 is suitable for DN80 pipelines, with a flow range of 9-135 m ³/h for liquid differential and 90-900 m ³/h for gas. The model OW-LU-100 is suitable for DN100 pipelines, with a flow range of 14-200 m ³/h for liquids and 140-1400 m ³/h for gases. The model OW-LU-150 is suitable for DN150 pipelines, with a flow range of 32-480 m ³/h for liquids and 300-3000 m ³/h for gases. The model OW-LU-200 is suitable for DN200 pipelines, with a flow range of 56~800 m ³/h for liquids and 550~5500 m ³/h for gases. Based on the above information, you can choose a suitable steam vortex flowmeter according to your pipeline diameter and understand the flow range it can measure. The steam vortex flowmeter is mainly used for measuring the flow rate of steam medium fluid in industrial pipelines. The characteristics of steam vortex flowme
2. What are the measurement ranges of vortex flowmeters?
1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;
2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;
3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15
1.2-6; DN20
1.5---10； DN25：2---16； DN32
1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130； DN100：18---160； ..... Gas measurement: (unit: m3/h): DN15:4--28; DN20：6---40； DN25：8---50； DN32：15---150； DN40：18---180； DN50：25---480； DN65：50---500； DN80：80---800； DN100：120---1200； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangqiang Automation Technology Co., Ltd.... Www.qszdh.com
3. How to choose a steam flowmeter? Pipe diameter DN150, maximum pressure 1.6MPa
You can use an integrated orifice plate (compact orifice). If using a vortex turbine, 1.6MPA is not a problem. Please note your steam temperature: ************* Process Temperature Limits Standard -40 to 450 ° F (-40 to
