1. Calibration Specification for Online Flow Meter

The calibration of online flow meters must strictly follow the standard process, which includes three main modules: calibration preparation, method selection, and operation steps. The specific execution must match the equipment characteristics and environmental requirements. 1. Calibration preparation • Understanding the characteristics of the flowmeter: Accurate calibration requires mastery of the measurement principle, range, medium type, and other parameters of the calibrated flowmeter. Before calibration, it is necessary to consult the technical manual to clarify key indicators. Calibration equipment selection: Select the corresponding method equipment according to the type of flowmeter, for example, the standard meter method requires that the accuracy of the standard flowmeter is at least one level higher than that of the calibrated meter, and the range covers the operating conditions of the calibrated meter. Environmental condition confirmation: Laboratory calibration needs to control temperature and humidity, and on-site calibration needs to meet the actual usage conditions of instruments, such as pipeline layout, fluid cleanliness, etc. • Personnel qualification review: Only calibration personnel holding valid certificates can operate and issue certificates to avoid data failure caused by unqualified personnel intervention

2. Common calibration methods • Volumetric method: Calculate flow rate by measuring the volume of fluid entering a constant volume container, suitable for scenarios with conventional liquids and moderate accuracy requirements. Quality method: Weigh the fluid mass to convert the flow rate, suitable for high-precision requirement

s or situations where the density of medium excavation and interception fluctuates greatly. Standard table method: Connect the standard table and the calibrated table in series, compare the reading deviation between the two, and ensure that the straight pipe section of the pipeline meets the requirements of balanced installation during operation to avoid flow field disturbance. • Standard volume tube method: dynamic volume measurement, suitable for systems with frequent flow rate changes, commonly used in industrial scenarios such as oil and gas. Standard table matching: Select a standard table with an error limit of 1/3-1/10 of the calibrated table, and the range should cover the actual working range of the calibrated table. Multi condition testing: Select 5 or more flow points within the range of 10% -100% for measurement, and record the data of both parties synchronously after stabilizing the flow state each time. For example, high flow points should be adjusted from downstream valves first to avoid sudden changes in gas medium pressure. Data processing: Calculate the indication error and repeatability index, compare with the manufacturers nominal error limit, determine whether it is qualified, and form a calibration report.

2. Flow Meter Calibration Regulations

The calibration of different types of flow meters must strictly match the corresponding national/international metrological standards and regulations. The specific calibration requirements are summarized below according to common categories.

Orifice flow meters must comply with JJF 2033-2023 "Orifice Flow Meter Calibration Specification", which covers the entire calibration process of measurement principles, measurement requirements, environ
