1. Is the Dearba flowmeter a Dearba flowmeter? Dearba Overview Dearba averaging tube flowmeter has a simple structure, easy installation and disassembly, low pressure loss, and low use and maintenance costs. In todays world where energy is increasingly scarce due to rapid economic development, Dearba averaging tube flowmeter is an energy-saving flowmeter worth promoting and using, especially in pipelines with a diameter greater than 200 millimeters. The advantages of averaging tube flowmeter are more obvious. Therefore, in industries such as power, metallurgy, and petrochemicals, the averaging tube flowmeter is often used as the preferred instrument. According to a survey conducted by authoritative foreign industry institutions on the global flow meter market in the past two years, the number of commonly used flow meters ranked 8th to 9th, with a total global on-site usage of

. Secondly, the working principle and flow calculation formula of Dearbar flow meters are measured by the differential pressure generated before and after the fluid using its unique sensing probe. When fluid flows through the probe, a high-pressure distribution area is generated in its front, and the pressure in the high-pressure distribution area is slightly higher than the static pressure of the pipeline. According to the Bernoulli equation principle, the velocity of the fluid increases when it flows through the probe, and a low-pressure distribution area is generated in the rear of the probe, and the pressure in the low-pressure distribution area is slightly lower than the static pressure of the pipeline. After the differential pressure fluid flows through the probe, vortices appear on both sides of the probe, and a partial vacuum is ge

nerated at the rear of the probe. Transfer the average high pressure in the high pressure area to the positive pressure chamber of the differential pressure instrument through the probe high pressure conduit; The average low pressure in the low pressure area is transmitted to the negative pressure chamber of the differential pressure instrument through a probe low pressure conduit. The differential pressure instrument measures the difference between the average high pressure and the average low pressure, and after square root calculation, it reflects the magnitude of the average flow velocity of the fluid. The average flow velocity is proportional to the flow rate, and can then calculate the volume flow rate or mass flow rate of the fluid in the pipeline. Flow meter Shanghai Menghui.

III. System Composition, Main Technical Indicators, and Application Fields

System Composition The Dearbar Equalizer Flow Meter system mainly consists of three parts: (see figure below)

(1) Primary Source Part: Dearbar Sensor Probe

(2) Differential Pressure Conversion Part: Differential Pressure Transmitter or Flow Converter

(3) Flow Display Accumulation Part: Flow Accumulator Secondary Instrument or PLC/DCS System. The Dearbar Flow Sensor is a high-performance flow sensor designed using the differential pressure working principle and online insertion installation method to accurately calculate and generate unique professional data through model data.

. It is a special throttling device whose output is differential pressure. The sensor measures pressure through a probe, which has two rows of unevenly distributed pressure holes in front and behind it. By averaging the different pressures or flow rates of the p
