1. What is the reason for the negative pressure of the flowmeter?
When the flowmeter pressure displays negative, it is usually caused by three types of problems: measurement system, process system, or instrument failure. one Measurement system issue ① Zero drift: After long-term use of the flowmeter, the sensor may experience zero drift, causing a change in the starting measurement point and displaying negative pressure. ② Improper installation: If the installation position vibrates violently or the pressure port is blocked, it may interfere with sensor data and cause negative values. two Problem with the Gongyu Zhaoyi system: ① Abnormal fluid flow: When the pipeline suddenly changes diameter or the valve quickly closes, the fluid forms vortices or local negative pressure, manifested as negative pressure. ② System suction phenomenon: If there is a vacuum pump or other equipment running in the system, the pressure in the suction area may be lower than atmospheric pressure, resulting in negative display. three Instrument malfunction ① Sensor damage: When the sensor is damaged due to aging, corrosion, or external forces, the measurement may be inaccurate and negative pressure values may occur. ② Signal transmission issues: Short circuits, open circuits, or poor contacts in the circuit can cause signal distortion, resulting in incorrect negative values being displayed. During processing, step-by-step troubleshooting can be carried out: first check the installation and pressure port status, then observe whether there are suction or flow abnormalities in the system, and finally verify whether the instrument itself is faulty by calibrating or replacing the sensor.
2. Why do electronic flow meters display nega
Electronic flow meters display negative numbers mainly due to factors such as flow errors, signal interference, and equipment failures.
. 1. Flow direction issue: Electronic flow meters usually measure fluids in the preset direction. If the actual flow direction is opposite to the design direction (such as pipeline system valve misoperation or pressure sudden change causing backflow), the instrument will record negative values due to reverse flow. This situation is more common in scenarios involving complex pipelines such as chemical engineering and water treatment. 2. Abnormal signal transmission, electromagnetic interference, and distortion of pulse signals collected by sensors. When the flowmeter is installed near strong electromagnetic equipment such as large motors and frequency converters, clutter may trigger the reverse flow calculation logic. Some cases have shown that unshielded signal cables can also experience similar faults in thunderstorm weather. 3. When the hardware of the equipment malfunctions and the aging of the sensor leads to an imbalance in the pure sensitivity of the electrode difference, it may mistakenly identify forward flow as reverse flow. Damage to the analog-to-digital converter in the circuit board can also result in abnormal negative values. In a certain refinery, a continuous negative value alarm was triggered due to a capacitor explosion on the flowmeter main board. 4. Parameter configuration errors can lead to uncalibrated flow zero points for newly installed flowmeters, resulting in benchmark deviations. During the debugging phase of a food factorys production line, due to the lack of setting medium density parameters, the air traffic control status displayed ab
