How to install a turbine flowmeter correctly? The turbine flowmeter is composed of a turbine flow source sensor and a display instrument, and is an ideal flowmeter for liquid flow measurement. Flow meters have the characteristics of simple structure, high accuracy, and easy installation, maintenance, and use. Turbine flowmeters are widely used in fields such as petroleum, chemical, metallurgical, water supply, papermaking, environmental protection, etc. How to install turbine flowmeter:
1. Turbine flowmeter can be installed horizontally or vertically. When installed vertically, the fluid flow direction should be from bottom to top, and the liquid must fill the pipeline without bubbles. The flow direction should be consistent with the arrow indicating the flow direction on the sensor housing. The upstream end should have at least a certain length of straight pipe section, with smooth, clean and tidy inner walls, and no defects such as dents, accumulation, peeling, etc.
2、 The axis of the sensor should be aligned with the axis of the adjacent hail pipeline. The gasket for connecting the seal must not penetrate deep into the pipe. Sensors should be kept away from external electric and magnetic fields. Effective shielding measures should be taken in the vicinity when necessary to avoid external interference.
3、 It is recommended to install a bypass pipeline at the location where the turbine flowmeter is installed to avoid affecting the normal transportation of liquids during maintenance.
4、 When impurities are present in the fluid, a filter should be installed with a mesh size of 20-60 mesh depending on the flow rate of impurities. When free gas is mixed in the fluid, an air purifier should be
5、 When impurities are present in the fluid, a filter should be installed. Users should fully understand the corrosion situation of the tested medium and strictly prevent the corrosion of the sensor.
6、 The installation method of flow meters on pipelines: Installing them on horizontal pipelines is a common installation method for flow sensors. When measuring liquids with a turbine flowmeter, if the measuring body contains a small amount of gas, the sensor should be installed at a lower position in the pipeline.
2. Entity List of Weishi Flow Meter
Currently, public information has not clearly indicated that Weishi Flow Meter is included in any countrys entity list.
. This brand focuses on the production and sales of industrial flow meters, and its products are widely used in multiple industries worldwide. One stop type, main product series 1 Gear flowmeter VS series: a high-performance model with a maximum pressure resistance of 700 bar, a measurement accuracy of ± 0.3%, and a flow range of 0.002-525 L/min. It is suitable for high-pressure precision applications such as hydraulic and automotive manufacturing. EF series: economical choice, pressure resistance of 200bar, accuracy of ± 2%, flow range of 0.05-150L/min, available for pipe thread and plate installation, suitable for cost sensitive eggplant liquid sensing applications. VHM series: made of stainless steel material, specially designed for non lubricating media, with a pressure resistance of 250 bar and an accuracy of ± 0.5%. It supports fibe
