1. Schematic diagram of V-cone flowmeter

nominal diameter: Φ 15- Φ 2000 measuring medium: liquid, gas, steam measuring medium temperature range: -200 ℃~+800 ℃ pressure level: dispersion 1.0MPa~10.5MPa accuracy level: 0.5 level, 1.0 level, 1.5 level, 2.5 level body material: cone material is stainless steel, pipeline and flange are carbon steel. (Other material agreement supply) β value range: 0.45... 0.85 nominal diameter: Φ 80- Φ 2000 measuring medium: liquid, gas, steam measuring medium temperature range: -200 ℃~+800 ℃ pressure level: 1.0MPa~10.5MPa accuracy level: 0.5, 1, 1.5, 2.5 table body material stool: cone material is stainless steel, pipeline, flange is carbon steel (other material agreement supply) β value range: 0.45... 0.85 nominal diameter: Φ 15- Φ 2000 measuring medium: liquid, gas, steam measuring medium temperature grinding range: -200 ℃~+800 ℃ pressure level

1.0MPa~10.5MPa accuracy level: 0.5, 1, Grade 1.5 and 2.5 body materials: The cone material is stainless steel, and the pipes and flanges are made of carbon (other materials are supplied according to the agreement). The beta value range is 0.45... 0.85

2 Why is it necessary to use a furnace specific V-cone flowmeter to measure furnace gas?

The gas in the kiln must be measured using a furnace specific V-cone flowmeter with silver fiber leakage, because V-cone flowmeters have the following advantages: high temperature resistance, vertical and high pressure characteristics: the working conditions of the kiln are very harsh, and the temperature and pressure may be very high.. The V-cone flowmeter can withstand high temperature and high pressure environments, making it very suitable for use in kilns. High precision mea

surement: The V-cone flowmeter can be flexibly adjusted and adapted to different flow ranges and intervals, achieving high-precision measurement and control for both small and large flow rates. This helps to improve the operational efficiency and product quality of the kiln. Good stability: The V-cone flowmeter adopts a special design principle to ensure the stability of gas flow, avoiding measurement instability caused by turbulence and turbulence. This stability is very important for the kiln industry because it not only ensures accurate measurement results, but also avoids equipment failures and production accidents caused by unstable gas flow. Strong adaptability: During the production process, the flow rate and speed of gas in the kiln will constantly change. The V-cone flowmeter can follow changes and achieve high-precision measurement and control for both small and large flow rates, thereby reducing errors and improving efficiency. Therefore, furnace gas must be measured using a furnace specific V-cone flowmeter.

3. Calculation formula and expression method for V-cone flowmeter?

What is the formula for the flow meter of the V-cone flowmeter, mainly the calculation method for measuring flow rate?. In the formula, Qv represents the volumetric flow rate of the fluid (under operating conditions), m3/sC represents the dimensionless coefficient of outflow, ε represents the coefficient of expansion of the measured medium, and ε=1 for incompressible fluids; Compressible fluids such as gases and vapors with ε<1 Δ p - differential pressure, Δ p=pH pL, Pa ρ A - density of the fluid upstream of the throttle element (front) under working conditions, kg/m3 β - equivalent diameter ratio, dimensionless. For a
